Engine (CC)
ARAI Mileage
Top Speed (KMPH)
Built around a diamond type frame, the CB Unicorn 150 is powered by a 149cc single-cylinder engine, which delivers 13bhp and 13Nm of torque and comes mated to a five-speed transmission. The powertrain is a super refined package that has played a major role in the reputation and cult following earned by CB Unicorn.
The motorcycle rides on 18-inch five-spoke alloy wheels shod with MRF Zapper tyres. The front wheel gets a 240mm disc brake with a two-piston floating caliper while the rear wheel gets a 130mm drum setup. The motorcycle now comes equipped with single-channel ABS for the front brake. Suspension duties are handled by telescopic forks at the front and a mono shock in the rear with adjustment for damping.
Compression Ratio--
Displacement149.1 cc
Cylinders1
Max Power12.73 bhp @ 8,000 rpm
Maximum Torque12.8 @ 5,500 rpm
Bore57 mm
Stroke57 mm
Valves Per Cylinder2
Fuel Delivery SystemCarburetor
Fuel TypePetrol
IgnitionDigital
Spark Plugs1 Per Cylinder
Cooling SystemAir Cooled
Gearbox TypeManual
No. of Gears5
Transmission TypeChain Drive
ClutchWet Multiplate
Front Brake TypeDisc
Front Brake Size240 mm
Rear Brake TypeDrum
Rear Brake Size130 mm
Calliper TypeFloating, two pistons
Front Wheel Size18 inch
Rear Wheel Size18 inch
Front Tyre Size2.75-18
Rear Tyre Size100/90-18
Tyre TypeTubed
Radial TyresNo
Wheel TypeAlloy
Front SuspensionTelescopic
Rear SuspensionMonoshock
Kerb Weight146 kg
Overall Length2,095 mm
Overall Width756 mm
Overall Height1,100 mm
Wheelbase1,340 mm
Ground Clearance179 mm
Seat Height--
Chassis TypeDiamond
Fuel Tank Capacity13 litres
Reserve Fuel Capacity--
Mileage60 kmpl
Fuel Efficiency Range780 Km
Top Speed101 Kmph
0 to 60 kmph--
60 to 0 kmph--
OdometerAnalogue
SpeedometerAnalogue
Fuel GuageYes
TachometerAnalogue
Stand Alarm--
Stepped SeatNo
No. of Tripmeters1
Tripmeter TypeAnalogue
Low Fuel IndicatorYes
Low Oil Indicator--
Low Battery Indicator--
Pillion BackrestNo
Pillion GrabrailYes
Pillion SeatYes
Pillion FootrestYes
Digital Fuel GuageNo
Start TypeElectric Start
Shift LightNo
Antilock Braking SystemNo
KillswitchNo
ClockNo
Electric System12V DC
Battery12V 7Ah
Headlight TypeHalogen And Bulb Type
Headlight Bulb Type12V 35/35W
Brake/Tail LightBulb Type
Turn SignalYes
Pass LightYes
